CNC 6-sided Drilling Machine ND512D

Highlights

  1. Multi-functional CNC drilling machine is able to drill from 6 sides.
  2. Simple routing meets different process requests and gives batch-size-one production max flexibility.
  3. Software is open port, support most formats in market.
  4. Machine is configured with one top and one bottom drilling blocks,one 3.5kw top main spindle.

Technician Data

ModelND512D
Panel sizeThickness：10-60mm    Width：30-1200mmLength： 200- 2800mm
Max speed（X/U/Y/Z）135/75/30m/min
Spindle powertop：3.5kw×2，bottom：3.5kw
Max speed（X/U/Y/Z）135/135/75/30m/min
Vert.drill10×2 / 9
Horiz. drillX direction：2×4  Y direction：2×2
Total power24.7kw
Control systemSYNTECH
Machine size3962×2810×2220mm
